MS & ERW Pipes


Mild Steel Electric Resistance Welded Pipes (MS ERW Pipes) have a carbon content of less than 0.18%. They are not considered hardened pipes since they have low carbon content. They are also called ‘Black Pipes’ since they are not galvanized. Mild steel is available in a variety of structural shapes that are easily welded into pipe, tube, tubing etc. Mild steel pipes and tubes are easy to fabricate, readily available, and cost less than most other metals. In well protected environments, the life expectancy of mild steel pipe is 50 to 100 years.


Generally, these pipes are coated with other metals such as copper, to protect from corrosion. Mild Steel pipes and tubing are used for structural purpose and mechanical & general engineering purpose. It is also used for drinking water supply and the use of chlorination and sodium silicate inhibit corrosion in mild steel pipes. Extra care is always required to keep mild steel pipes from rusting.
Application
Our clients can avail a complete gamut of mild steel pipes to suit their varied requirements. Our mild steel pipes are fabricated using superior quality steel at the manufacturers' end. These are extensively used for heat transfer in process equipment like boilers, super heaters, heat exchangers and condensers. Further, these can be availed in various specification at industry leading prices.
N.B. & Series Outside Diameter Wall Thickness

Nominal Weight Black Tubes

Nominal Weight Black Tubes Nominal Weight Galvanised Tubes Nominal Weight Galvanised Tubes
mm Minimummm Maximummm mm SWG P.E S&S P.E. S & S P.E. S & S P.E. S & S
kg/m kg/m m/tone m/tone kg/m kg/m m/tone m/tone
15
(1/2")
L 21.00 21.40 2.00 14 0.947 0.956 1056 1046 0.947 0.956 1056 1046
M 21.00 21.80 2.60 12 1.21 1.22 826 819 1.21 1.22 826 819
H 21.00 21.80 3.20 10 1.44 1.45 694 689 1.44 1.45 694 689
20
(3/4")
L 26.40 26.90 2.30 13 1.38 1.39 724 719 1.38 1.39 714 719
M 26.50 27.30 2.60. 12 1.56 1.57 641 637 1.56 1.57 641 637
H 26.50 27.30 3.20 10 1.87 1.88 534 532 1.87 1.88 534 532
25
(1")
L 33.20 33.80 2.60 12 1.98 2.00 505 500 1.98 2.00 505 500
M 33.30 34.20 3.20 10 2.41 2.43 415 411 2.41 2.43 415 411
H 33.30 34.20 4.00 8 2.93 2.95 341 339 2.93 2.95 341 339
32
(1 1/4")
L 41.90 42.50 2.60 12 2.54 2.57 393 389 2.54 2.57 393 389
M 42.00 42.90 3.20 10 3.10 3.13 322 319 3.10 3.13 322 319
H 42.00 42.90 4.00 8 3.79 3.82 264 261 3.79 3.82 264 261
40
(1 1/2")
L 47.80 48.40 2.90 11 3.23 3.27 309 306 3.23 3.27 309 306
M 47.90 48.80 3.20 10 3.56 3.60 281 277 3.56 3.60 281 277
H 47.90 48.80 4.00 8 4.37 4.41 229 226 4.37 4.41 229 226
50
(2")
L 59.60 60.20 2.90 11 4.08 4.15 245 241 4.08 4.15 245 241
M 59.70 60.80 3.60 9 5.03 5.10 199 196 5.03 5.10 199 196
H 59.70 60.80 4.50 7 6.19 6.26 161 159 6.19 6.26 161 159
65
(2 1/2")
L 75.20 76.00 3.20 10 5.71 5.83 175 171 5.71 5.83 175 171
M 75.30 76.60 3.60 9 6.42 6.54 155 153 6.42 6.54 155 153
H 75.30 76.60 4.50 7 7.93 8.05 126 124 7.93 8.05 126 124
80
(3")
L 87.90 88.70 3.20 10 6.72 6.89 149 145 6.72 6.89 149 145
M 88.00 89.50 4.00 8 8.36 8.53 119 117 8.36 8.53 119 117
H 88.00 89.50 4.80 6 9.90 10.10 101 96 9.90 10.40 101 96
100
(4")
L 113.00 113.90 3.60 9 9.75 10.00 102 100 9.75 10.00 102 100
M 113.10 115.00 4.50 7 12.20 12.50 80 80 12.20 12.50 82 80
H 113.10 115.00 5.40 5 14.50 14.80 69 67 14.50 14.80 69 67
125
(5")
M 138.50 140.80 4.80 6 15.90 16.40 63 61 15.90 16.40 63 61
H 138.50 140.80 5.40 5 17.90 18.40 56 54 17.90 18.40 56 54
150
(6")
M 163.90 166.50 4.80 6 18.90 19.50 53 51 18.90 19.50 53 51
H 163.50 166.50 5.40 5 21.30 21.90 47 45 21.30 21.90 47 45
